Utility set heavy duty restaurant exhaust fan 5000 cfm
Utility Set Heavy Duty Restaurant Exhaust Fan 5000 cfm
High Velocity, Restaurant-Duty Utility Set with a 16" Wheel Exhaust Motor:Model 00218OS3EF56Z-40PP, 2 HP, 3 Phs, 208 V, 6.0 FLA, ODP (Open Drip Proof) Exhaust Motor Exhaust Performance:Volume: 3000 cfm RPM: 1706 TS: 7369 ft/minSP: -1.5" w.g. BHP: 1.803 -Virtually grease-free rooftops. -No added options needed. -No pre-mature motor failures. -Handles high temperature, heavy grease applications. -Curb mounted design. - Pleasing aesthetics - high quality enamel painted housing. -Ventilated motor housing for motor, shaft and drive protection. -Rigid motor plate assembly. -Non-overloading, welded steel backward inclined wheel is statically and dynamically balanced and permits usage on high static pressure applications. -Balancing weights are mechanically fastened. -Heavy duty bearings in excess of 200,000 hours of operation. -Motor base and shaft seals provide a double layer of protection to eliminate water leaks into the building and grease build-up on motor. -Grease laden air does not enter the motor compartment, increasing the life of the motor and allowing use on high temperature and grease applications. -Discharge section continuously welded to avoid grease leakage. -Continuously welded scroll to prevent grease leakage onto the rooftop. -Grease drain centered and fully welded onto discharge elbow. -Newly engineered hinged base for improved installation.
Please call toll free with any questions.
