> Ex-cell-o 602 milling machine operator parts manual xlo
Ex-cell-o 602 milling machine operator parts manual xlo
Ex-Cell-O Ram Turret Milling Machine Style 602
Operation and Instruction Manual
This is a reproduction, not a photocopy, of an original Ex-Cell-O Ram Turret Milling Machine Style "602" Operation and Instruction Manual. This manual contains information on lubrication, adjustments, maintenance, and controls as well as a complete parts list with exploded view diagrams.
Machine Specifications...............................2
Installation.........................................3
Operating Instructions.............................4-5
Adjusting Gibs.......................................6
Aligning Head........................................6
Adjusting Backlash Eliminator Nuts..................6
Ordering.............................................7
Head Temperature.....................................7
Spindle Brake & Lock.................................7
Spindle Belt Replacement.............................7
Replacing Quill Return Spring........................7
Replacing Quill Guard................................8
Replacing R-8 Drive Key..............................8
Table Power Feed.....................................8
Spindle Bearings.....................................8
Lubrication..........................................9
Manual System....................................10-11
One Shot System..................................12-13
Automatic System.................................12-13
Head Drive.......................................14-16
Head Body Assembly...............................16-20
Spindle Assembly....................................21
Dovetail Ram Assembly............................22-23
51/2 Riser Assembly.................................23
Machine Assembly.................................24-27
Table Power Feed Assembly........................28-29
Right Angle Attachment Assembly..................30-31
Horizontal Mill Attachment Assembly..............30-31
Anti-Backlash Nut Assembly..........................32
