Smart sub-meter electric energy kwh 120V free software
120 Volt, 2-wire, 60Hz, Model EKM-15EDS-N v.2
BRAND NEW PRODUCT!!-This is a revolutionary **Smart Meter** at an extraordinary price!!!
EXTERNAL Current Transformer (CT) type for ease of installation. 1 CT per meter required. (CTs sold separately- -Here- Or see my other listings)
SMARTER than ever!! Reads kWh, Reverse kWh, Voltage, Current, Power, Power Factor, Maximum Demand, 6 months of monthly reads stored
on-board the meter with 4 TOU rates, 4 Times of day and 4 Seasons!! All readable and logable via RS-485 and user friendly PC, Mac and Linux software.
** MORE ACCURATE than ever!! Class 0.5 (+/-0.5% over all but the very lowest end of the 200A current range)
Built-in data storage and RS-485 Serial Communication for reading kWh usage remotely!!
FREE PC, Linux and Mac software to read the meter kWh data remotely!!
Connect to your computer via 2-wire RS-485- - -Easy to connect 2-wire, daisy-chained network!
Up to 32 meters can connect over 4000 feet to one serial or USB port on your computer!
Low-cost, tested, compatible, USB and serial port converters available!
Or - - Connect up to 32 meters to one $65 Internet-connected device for world-wide access!
Each meter has it's own network address!
State of the art, solid-state, digital energy meter
Compact, easy-to-install design
Monitor all critical circuits in your home or business
Pulse output-800 pulses per kWh
Not available anywhere else!! This is a TOTALLY unique product!
Watertight enclosures available
This is a brand new kWh meter design, manufactured for EKM Metering, the most advanced type electronic KWH meter available on the market, model EKM-23EDS-N, v.2, 2 wire, 200 amp version. These were made specifically for 2-wire 230 Volt (range: 156v-312v) single phase metering. Installation is easy with External Current transformers (CTs). However, installation should only be performed by a knowledgeable, qualified electrician. The 2 service wires pass through the CTs, available as closed or openable. Separate 230V connection required to power the meter-less than 1 watt required. Installation and instruction manual included. Dimensions are approx. 3"w x 4"h x 2.5"d.
The meters have a non-resetable, 5 digit LCD readout with hundredths, and read directly in kWh, no conversion factors as with some other electronic meters. They also have built-in data storage which is readable via a 2-wire (with ground) RS485 serial connection to your PC (connections A,B and G in the photo). In addition, they have a built-in PULSE OUTPUT, 800 pulses per kWh. They are perfect for remote and automatic meter reading (AMR) applications.
Use these meters to measure and keep track of kilowatt hours and energy usage for sub panels or individual pieces of equipment. I can supply any number of these you need.
***Please Note-8 of the photos in this listing are for illustration purposes, and may show something NOT included with the listed item. This listing is for the meter ONLY. CTs, DIN-rail, and converters are sold separately.
Although the TCP/IP to RS-485 converter is quite a bit more expensive, I highly recommend it. With the meters connected to this device, and the device connected to your LAN or router, you will be able to read the meters from anywhere, not just locally, but anywhere in the world!!! **** If you want to see how this works, download the software and run the appropriate application from the downloaded folder. You will be able to read my test meters from your PC, Linux box, or Macintosh running OS X. These meters are connected to the TCP/IP to RS-485 converter at my test site.
Also available in a 120/240V, 3-wire version, a pass-through version, and a 230V, 2-wire volt version for the rest of the world.
For CTs or if you need other types of kWh meters-please take a look at my other items for sale!
100% Satisfaction Guaranteed!! Return within 30 days if you are not completely satisfied. One year warranty from the manufacturer.
