Ic chips: SN74LV05AD hex inverters w. open-drain output
- Typical VOLP (Output Ground Bounce)
<0.8 V at VCC = 3.3 V, TA = 25 C
- Typical VOHV (Output VOH Undershoot)
>2.3 V at VCC = 3.3 V, TA = 25 C
- Support Mixed-Mode Voltage Operation on All Ports
- Ioff Supports Partial-Power-Down Mode Operation
- Latch-Up Performance Exceeds 250 mA Per JESD 17
- ESD Protection Exceeds JESD 22
- 2000-V Human-Body Model (A114-A)
- 200-V Machine Model (A115-A)
- 1000-V Charged-Device Model (C101)
