New faulhaber dc servo minimotor sa-24 volt/23,000 rpm
NEW Faulhaber DC Servo MiniMotor SA-24 Volt/23,000 RPM
This is a New Faulhaber DC Servo MiniMotor SA. This item is used in a wide variety of small industrial machinery. It is a 24V, 23,000 RPM motor. Cosmetically, it is new and flawless. The photos show a typical item. Only what is shown in the photos is included.
* Terminal resistance, phase-phase: 2,1 Ohms
* No-load current (with shaft 3,0 mm): .184A
* Friction torque, static: 1.00 mNm
* Friction torque, dynamic: 3,5 .10-5 mNm/rpm
* Back-EMF constant: 1026 mV/rpm
* Torque constant: 9,8 mNm/A
* Current constant: 102 A/mNm
* Slope of n-M curve: 209 rpm/mNm
* Terminal inductance, phase-phase: 180 H
* Mechanical time constant: 14 ms
* Angular acceleration: 171 .103rad/s2
