Agilent hp E1301A 75000 series b vxi chassis
Agilent HP E1301A 75000 Series B VXI Chassis
The Agilent E1301A B-size VXI mainframe features improved dual fan cooling for support of the most demanding B-size modules, such as the E1312A. Two of its nine slots are located internally and are dedicated to housing the 2-slot E1326B Multimeter. The E1301A Mainframe features a built-in high-performance command module (functionally identical to the E1306A Command Module) with built-in GPIB interface. The E1301A Mainframe is identical to the E1300A in function, but features a front panel and keyboard for manual control and troubleshooting without the use of GPIB. This makes it an ideal mainframe for remote applications.
The HP 75000 Custom Systems are built on a flexible architecture that allows you great versatility in the way you configure your system. The Series B cardcage is a modular architecture designed to configure in minutes. Instrumentation and switch cards can be easily inserted into slots in the rear of the instrument. When the cardcage is truned on, it automatically identifies the cards and sets the menu accordingly.
* Front panel for manual control Low-cost, compact mainframe
* Built-in command module GPIB interface and Resource Manager SCPI for easy programming
* VXI device type: Mainframe Data transfer bus: 16 bits
* Size: B Slots: 9 (7 external, 2 internal, 3 external A-size)
* Overall condition is good to fair, see photos.
