New jet 16" open stand planer 708531
JET JWP-16OS, 16" Open Stand Planer
* Cast iron and steel construction provides strength and durability
* Cutter head with three high-speed steel knives locks firmly in place to prevent movement while in use
* Large cast iron hand wheel makes easy table height adjustments with less effort
* Surge in feed and out feed rollers give your work piece maximum support during planing operations
* Power 3 HP motor uses three V-belts to deliver consistent, smooth power
* Exclusive angled 4" dust port keeps dust hose out of the way while providing efficient chip and dust removal
* Heavy-duty steel wide base open stand with casting pads provides support and stability of the tool during use
Maximum Planing Thickness 6" Motor 3 HP; 1 Ph 230V Cutter Head Speed 4,500 RPM Cutter Head Diameter 2-7/8" Feed Rates 16 and 20 FPM Maximum Planing Width 16" Minimum Planing Length 6" Dust Port Diameter 4" Maximum Full Width Depth Of Cut 1/8" Blade Size 16-1/8" x 1" x 1/8" (L x W x T) Number of Knives 3 Maximum Depth of Cut 3/16" Maximum Opening 6-3/8" x 16" Cuts per Minute 13,500 CPM Overall Dimensions 48" x 32" x 51" (L x W x H) Net Weight 396 lbs.
* 16" Open Stand Planer - 708531
