T1 line seiki incremental shaft rotary encoder cb-500HC
Line Seiki Incremental Shaft type Rotary Encoder CB Series CB-500HC
Our Sensors range is a collection of auxiliary products to address the sensing needs of our products. These are completely compatible with our Counters range.
Incremental Shaft type Rotary Encoder
The CB Series is an incremental encoder which generates certain number of pulses for every complete revolution. Our CB Series are fully compatible with our counters. It is available in different Pulse per Revolution (PPR) ranging from 100 PPR to 2500 PPR. It also has a universal mounting hole configuration which makes a worry-free replacement of any other encoders.
* Outside: 38 (Shaft: 6), PCD 30
* Wide Range of High Resolution Models
* High Reliability and Performance
* Universal Mounting - Fits to almost all
Standard Mounting dimensions
* Suitable for General or Industrial
Signal Rise/Fall Time (Pull-up resistor 2.2k ,1m Cable)
Approx. 120g (with 0.5m Cable)
-10 ~ +70 (Non-Condensing, Non-Freezing)
-25 ~ +80 (Non-Condensing, Non-Freezing)
10~55 Hz, Width (P-P) 1.5mm (2 hours each in X, Y, Z Direction)
6 ms, 980 m/s (3 times each in X, Y, Z Direction)
