Honeywell visionpro 8000 programmable thermostat, 1
Condition: New Finally, a programmable thermostat that almost reads your mind. Honeywell's VisionPRO 8000 thermostat is the easiest-to-use thermostat ever.
Honeywell VisionPro 8000 Programmable 1 Heat/1 Cool Thermostat
Effortless, Menu-Driven Programming - Simplifies programming by responding to your choices - offers 7-days programming with 4 periods per day.
Energy Savings - You can save up to 33% on annual heating and cooling costs.
Large, Clear Backlit Digital Display - Easy to read in various lighting conditions (can be permanently backlight with use of "common" wire).
Real-Time Clock - Keeps time during power failures and automatically updates for daylight savings.
Change/Check Reminders - Lets you know when to service or replace filters, batteries, etc.
Multiple HOLD Options - Allows you to override the program schedule as desired with temporary and vacation hold settings.
Precise Comfort Control (+/- 1 F) - Maintains consistent comfort at the highest level of accuracy.
Programmable Fan - Offers "CIRC" mode to run fan randomly approximately 35% of time. Provides improved air circulation for more efficient central air cleaning when you do not want the fan running continuously.
Remote Sensor Terminals - connect optional indoor or outdoor remote sensor do display temperature at remote location
Dimensions - 6" W x 4 9/16" H x 1 1/8" D
Single stage gas, oil, or electric heat with single stage air conditioning
Warm air, hot water, highefficiency furnaces, single stage heat pumps with NO auxiliary or emergency heat, steam, gravity
Heat only two-wire systems, power to open and close zone valves (Series 20), and normally open zone valves
750 mV (milivolt) heating systems
Description - VisionPRO Touchscreen 7-Day Programmable 1 Heat/1 Cool Conventional and Heat Pump Thermostat
Application - Conventional and Heat Pump systems
Programmability - Universal Programming from 7 Day to Non-Programmable
Changeover - Auto/Manual Selectable
Switch Positions (System) - HEAT-OFF-COOL-AUTO
Switch Positions (Fan) - AUTO-ON-CIRC
Power Method - Battery or Hardwired
Terminal Designations - R, RC, C, W (O/B), Y, G, S1, S2
Dimensions (in.) - 4 9/16 in. high x 6 in. wide x 1 1/4 in. deep
Dimensions (mm) - 116 mm high x 152 mm wide x 32 mm deep
Setting Temperature Range (F) Heat: 40 F to 90 F; Cool: 50 F to 99 F
Setting Temperature Range (C) Heat: 4.5 C to 32 C; Cool: 10 C to 37 C
Differential Temperature (F) 1 F
Differential Temperature (C) 0.5 C
Outdoor Sensor - Yes, optional outdoor or indoor remote
Remote Sensor - Yes, optional outdoor or indoor remote
Operating Humidity Range - (% RH) 5 to 90% RH, non-condensing
Comments - Selectable to and Heat Only or Cool Only
Voltage - 20 to 30 Vac or 750 mV
