Daewoo lynx 200A cnc lathe, fanuc 21T
Daewoo Lynx 200A CNC LATHE, Fanuc 21T
Daewoo Lynx 200A CNC Turning Center
Swing Over Bed: ..................18.11"
Swing Over Saddle: ...............13.78"
Recommended Machining Daimeter: ..6.5"
Maximum Machining Diameter: ......11.02"
Maximum Work Length: .............11.81"
Draw Tube Diameter: ..............1.77"
X-Axis Travel: ...................6.3"
Z-Axis Travel: ...................13"
Spindle Chuck Diameter: ..........6.65"
Spindle Speed Range: .............50 - 5000 RPM
Spindle Nose: ....................A2-5
Spindle Bore Diameter: ...........2.09"
Turret Number of Stations: .......12
Tailstock Quill Diameter: ........2.56"
Tailstock Quill Travel: ..........3.15"
Spindle Drive (Cont/30 Min): .....7.5/10 HP
