Controller for rgb led lights 12V/5A/3 channels, remote
Controller for RGB LED lights 12V/5A/3 channels, Remote
Controller for RGB LED modules / Ribbons / Tubes , 12V/5A/3 channels
Full-color multifunction controller is dedicated to control color changes of LED lights with 4-pin 3-loop cables (common anode).
It can be controlled through manual buttons and its match remote controller.
Also, this unit can run standalone or networking with multi controllers.
Output Power: 1 - 120W (8V), 1-220W (12V), 1-400W (24V)
Gray Scale: 256 level per RGB
Brightness Adjust: 0-8 levels
Protection: auto overload protection
Dimension: 8 3/8" x 1 5/8" x 1 2/8"
Remote controller distance can reach as far as 50m
1-16 speed levels for each mode
0-8 brightness levels for each mode
The current color depth of LED light can be stored with the function of Pause
One years manufacturer direct warranty with invoice
RGB LED controller with remote
M5 - M11: Seven Fixation colors
PAUSE (press to stay at the current color, press again any button, color change continues)
SPEED+ (to increase speed by every press)
SPEED- (to decrease speed by every press)
Conjunction Diagram (LED modules as an example)
