Plc industrial software training examples w manual cd
PLC Programming and Simulator Software
No controller needed Virtual PLC operation on your PC
Includes digital and analog input functions.
Software for Programmable Logic Controllers (PLCs)?
Learn ladder logic and the Easy to use function logic (all in one package)
Program PLCs in the comfort of your own time in your PC.
PLC Programming & Simulator Software comes with most of the features of the HI-end industrials PLC's instructions
such as in Allen-Bradley, Siemens, Mitsubishi, Electrodepot, Fanuc, Omron etc.
Ideal for engineers or students who whish to prepare real projects and exercise any automation challenge
Select the programming of your choice:
RLL (relay ladder logic) or FBD (function block diagrams)
CD ROM with software, electronic instructions manual and examples
PLC Program and Simulator features include:
Featured: inputs, outputs and functions
* Input Switches operable from the computer keyboard or by clicking on them.
* Instantaneous Relay contacts (normally-open and normally-closed).
* Instantaneous Timer contacts (normally-open and normally-closed).
* Timed Timer and counter contacts
* Real Time Clock Day, Month, Years
* Compare Instructions (GRT, EQU, and LES).
* Analog inputs and scale simulator screen
* Master Control Relays (MCR)
* Math Outputs (ADD, SUB, MUL, and DIV)
* Logical Outputs (AND, OR, NOT, and XOR)
The software supplied can be used to program any EDPLC. Controller
1. Easy and convenient program creation and editing.
2. Programs can be saved on a computer and accessed at any time.
3. Programs can also be upload from the EDPLC controller and then edited.
4. Enables users to print programs for reference and review.
5. The Simulation Mode allows users to virtually run and test the program before it is loaded to the the EDPLC
6. Real-time communication allows the user to monitor the EDPLC operation during RUN mode
PLC Simulator Hardware/Software Requirements:
* IBM PC or higher compatible computer
* Windows operating system, XP , 2003, NT 4.0 , Vista, Windows 7
* Minimum of 128 megabyte of RAM memory.
* Minimum of 12 megabyte of available hard disk space.
* 800 x 600 or higher screen video capability.
* Optional Graphics-capable printer.
XP.Vista, Windows 7 are registred trade marks from Microsoft Corporation
