(100) pic 16C73 breadboard and printed circuit
These printed circuit boards are still in their original packaging and totally "as new". They measure 3-1/2 by 5-1/4 inches and are ideal for PIC analog input/ac power out applications. Especially for the 16C73B.
Yes, the boards are flash compatible!
Included are provisions for 110/220 vac onboard transformer driving a regulated 5 vdc supply, THREE 30 amp output power relays, analog and digital inputs, an optoisolator and a LM311 comparator.
We do not have the exact schematic nor the sourcecode, but this mixed surface mount and thru-hole board seems easy to trace and exceptionally easy to modify. Guaranteed usable.
PIC's from MicroChip Technology, transformers, relays, bridges, capacitors, crystals, and some other components are separately available. These are perfect for environmental and a/c controls, robotics, machine tool interface, general power control, and (with a simple mod) for automotive apps.
