USB2.0 LA1016 16 channels 100MHZ digital logic analyzer
LA1016 16 channels 100MHz Digital Logic Analyzer
Signal Sampling Rate: 100MHz(max)
* Real-time Displaying Rate 100MHz(max)
* Measuring Bandwidth 33MHz
* Storage Depth per Channel 32Kbits
* Input Signal Voltage Range 0 5V
* Triggering Voltage Type TTL/CMOS
* USB version USB2.0 full speed
* Hardware filtering 2 levels
* Trigger Position Setting Supported Allows any triggering position for better observations)
* Trigger Condition Levels 16 levels
* Supported Operating system Windows 2000 Windows XP
* Data width Trigger: Supported
* Data show up times Trigger Supported
* Data>,
* Visible Trigger Supported
* Smart warning Dynamic Measure
* Digital filtering Attaching markers
* Signal Group Multi-measure display
* Creating waveform pictures Waveform search
* Auto updating Multi interfaces styles
* CSV data export Add-on Toolbar
* UART bus Analyzer I2C Bus Analyzer
* Meiler data buses Analyzer A/D Transfer Analyzer
* SSI bus Analyzer SPI Bus Analyzer
* Manc Hester code Analyzer 1-Wire Bus Analyzer
* SD/MMC card SPI mode Analyzer
* CF card True IDE mode Analyzer
* 16X LA1016 measurement leads
* English Driver and manual on CD
