Power supply enclosed switching s-60-12 - 60W 12V 5A
S-60-12 - 60W 12V 5A Enclosed Switching Power Supply
20A/ 115V, 40A/ 230Vac, Cold start
300ms, 50ms/230Vac 800ms, 50ms/115Vac at full load
90ms/230Vac 12ms/115Vac at full load
Hiccup mode, recovers automatically after fault condition is removed.
Hiccup mode, recovers automatically after fault condition is removed
-10 C to +60 C (Refer to output load derating curve)
10 ~ 500Hz, 2G 10min./1cycle, period for60min. each along X,Y, Z axes
I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
UL 1012, UL1950, TUV EN60950 Approved
Compliance to EN55022 (CISPR22) Class B, EN61000-3-2,-3, ENV50204,
EN61000-4-2,3,4,5,6,8,11; EN55024, Light industry level, criteria A
316.2K hrs min. MIL-HDBK-217F (25 C)
