Aprilaire 8466 programmable universal thermostat
Condition: New Aprilaire 8466 Programmable Universal Thermostat
Aprilaire 8466 Programmable Universal Thermostat
Are you looking for an attractive thermostat that is packed with features but low on price? You have found it! The new Aprilaire 8400 series thermostats have all the features you are looking for at a value price!
Model 8466 is universal and will control - Standard Systems gas / oil / electric. Single Stage/Heat Pump/Multi-Stage, Millivolt Systems
* Large 4.5 square inch LCD with high contrast for easier reading
* Controls 3 Stages Heat / 2 Stages Cool
* Bright, white backlit display is easy to read
* Easy to use temperature control and override program schedule at anytime
* Choice of 5/1/1 day programmable, or 5/2 day
* Displays room temperature, temperature setting and outdoor temperature (with 8052 sensor) simultaneously
* Removable battery cover for fast, easy replacement
* Dual fuel operation built in eliminates need for a dual fuel kit (requires 8052 outdoor temperature sensor)
* Dual Powered...choice of battery powered or hardwired, for all applications
* Easy-to-wire terminal block
* Outdoor temperature (requires 8052 outdoor temperature sensor)
* Permanent memory retention during power outage
* Water panel, air filter, dehumidifier and HVAC service indicators
* Simple set-up menu to activate optional features
* Circulate fan mode (if the fan has been off for 20 minutes the fan will be activated for a 10 minute cycle. Use this mode for a balance of energy savings and air circulation/cleaning)
* Quick reference instructions on board
* Display temperature offset (+/-4 )
* Configures as manual heat/cool, or with auto changeover
* Adjustable differential for 1st, 2nd, 3rd stage
Terminals: Rc, R, W, Y, G, C, S1, S2, 0/B, L, W2, Y2
Operating voltage 24 VAC (18 30 VAC)
Current - Maximum: 2.5A (total), 1.0A (single output)
Power supply Dual power. Can be battery or 24 VAC powered (When both the sources are available, battery will be used as back up power.)
Battery power: AA size alkaline battery x 2
Battery life: Approximately 1 year
Outdoor temperature sensor Maximum distance: 300 feet
Room temperature measurement Display range: 32 to 99 F (0 to 40 C)
Outdoor temperature measurement Display range: -20 to 130 F (-30 to 55 C)
Heat: 45 to 90 F (7 to 32 C)
Cool: 50 to 99 F (10 to 37 C)
Dimensions: 5.25 x 4.50 x 1.00
